    54CM Height Carbon Road Disc Frameset T900 Carbon Fiber For Disc Brake Bike

    Ask Lasest Price
    Brand Name : TWITTER
    Model Number : CYCLONEpro-Disc frame
    Certification : CE RoHS REACH ISO9001
    Payment Terms : T/T, L/C, D/A, D/P, T/T, Western Union, alipay
    Supply Ability : 30000pc per month
    Delivery Time : 7-15 working days
    Price : Negotiable
    • Product Details
    • Company Profile

    54CM Height Carbon Road Disc Frameset T900 Carbon Fiber For Disc Brake Bike

    Light Weight Carbon Fiber T900 Disc Brake Road Bike Frame Inner Cable 54CM


    Feature:All cables inner Routing
    Frame Size(Height):45cm / 48cm / 51cm / 54cm
    Material:High modulus Carbon fiber(T900 mix)
    ASSY Size:700C, BB86*46 Pressed+Head tube 52*52&Cover, Hanging fixed to FD, Thru axle F12*100_R12*142mm, Flat-mount post, Inner fixed to seat post, max 700*28C tyre
    Process:XC-Racing, EPS, Inner-Cables, Matte or Gloss or Holographic color paint, UV laser colorful decals
    Weight:Frame 1.02KG, Fork 0.43KG, Seat post 0.19KG, Handlebar set 0.19KG

    Frame specification:

    sizeABCDEFGHIJK
    BB Center to Top of Seat TubeEffective Top Tube HorizontalBB offsetChainstay LengthSeat angleHead AngleFront CenterHead Tube LengthFork OffsetReachStack
    mmmmmmmm°°mmmmmmmmmm
    XS - 45cm450505-7440874.371.257010055363506
    S - 48cm480520-7440874.371.258811455374518
    M - 51cm510538-7440874.371.260713055388534
    L - 54cm540550-7440874.371.262015055394553


    Customized Service
    1. If you design by yourself, it is better if could provide us your design.
    Or we could design for you according to your requirement.
    2. MOQ is 300pcs/model
    3. Customized logo can be accepted.
    4. Color combination is available

    After-Sales Service
    1. Frame and fork: 1 year's warranty
    2. AII the electric components (including the battery); 2 year’s warranty
    3. Mechanical parts: 1/2 year's warranty

    Feedback
    Your satisfaction and positive feedback will be our best return for serving you.
    If you feel satisfied with our products and services, please leave us your positive feedback. Your feedback will be highly appreciated and will help us to serve you better. Thank you!If you are not happy with our products and services, please contact us before you submit a negative feedback. Once there is a problem reported, all of our staffs will try best to help you out of the issueoccurred.

    Different angle


    Carbon fork




    Hanger

    Why Chose Us
    - Factory price
    - Logo customized
    - Customized packages
    - A lots of color for your choice
    - OEM manufactured and popular design
    - CE, SGS, and other certificates
    - Lifelong aftersales tracking
    - Stable supply and fast delivery

    FAQ
    1. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    2. what can you buy from us?
    Bicycle, Bicycle-parts, E-bike

    3. why should you buy from us not from other suppliers?
    Our company has 10 years experiences in R & D and manufacturing for High-end bicycles, Electric bicycle and related products.
